Products / Luxume
Luxume
Luxume Roofing presents premium colour-coated roofing sheets crafted to deliver dependable strength, long-term durability, and reliable protection across every climate condition.
Why choose Luxume?
Engineered for Strength
Manufactured using high-grade coated steel to ensure enhanced durability and structural stability.
Enhanced Corrosion Resistance
Aluminium-Zinc coating technology provides reliable protection against rust and environmental wear.
Performance in Every Climate
Designed to perform efficiently in coastal regions, humid weather, heavy rainfall, and high temperature conditions.
Aesthetic Colour Options
Offered in a selection of contemporary and classic shades to suit diverse architectural styles.
Long-Lasting Surface Protection
Advanced coating systems help preserve appearance and minimise maintenance requirements over time.
10-Year Product Guarantee
Supported by a 10-year Guarantee that reflects the product’s quality and durability standards.
Wide Range of Colours
Choose from our extensive palette of premium finishes, designed to complement any architectural style.
Select a colour
Profile Types
Explore the variety of profiles available for Luxume, engineered for strength, aesthetic appeal, and performance.
Trafford sheet
Width 1100mm 5 crests double ribbed
Trafford sheet
Width 1100mm 6 crests double ribbed
Cladding sheet
Width 1130mm with 14 corrugations.
Profile Ridge
8 feet long
Corner Flash
8 feet long
Ridges
8 feet long
Technical Specifications
Base metal standard
NAIS:15961 Grade
Length
feetCustomizable up to 26 feet
Width
mmTrafford-1100 , Cladding -1113
Thickness
mm0.35, 0.40, 0.45, 0.47, 0.50
Yield strength
MPaYS 550 minimum
Coating Mass
gsmAZ 70
Total Paint Coating Thickness
µm35
Top coat paint type
NARMP(Optional -SMP/SDP/PVDF)
Top coat paint colour
NAAll RAL Colours
Bottom coat paint type/colour
NAEpoxy / Grey
Protective Film
NAOptional 50µm protective guard film
Salt Spray Test
HrsTop: 750 Hrs, Bottom: 300 Hrs
Humidity Test
HrsTop: 750 Hrs, Bottom: 300 Hrs
Scratch Hardness Test
KgTop: 1.5Kg pass, Bottom: 0.7Kg pass
Pencil Hardness
NAH pass
Cross Hatch
NANo Tape loss
Bend Test top/bottom
Thickness4T pass
Gloss Test @60 degree top/bottom
%35 +/- 5
Solvent Rub test
DRTop: 100 rubs, Bottom: 50 rubs pass
Liner marking
NA
LUXUME 0.35 MM TCT PPGL AZ70 GSM 550 MPa DD/MM/YYYY
| Parameter | UOM | Specification |
|---|---|---|
| Base metal standard | NA | IS:15961 Grade |
| Length | feet | Customizable up to 26 feet |
| Width | mm | Trafford-1100 , Cladding -1113 |
| Thickness | mm | 0.35, 0.40, 0.45, 0.47, 0.50 |
| Yield strength | MPa | YS 550 minimum |
| Coating Mass | gsm | AZ 70 |
| Total Paint Coating Thickness | µm | 35 |
| Top coat paint type | NA | RMP(Optional -SMP/SDP/PVDF) |
| Top coat paint colour | NA | All RAL Colours |
| Bottom coat paint type/colour | NA | Epoxy / Grey |
| Protective Film | NA | Optional 50µm protective guard film |
| Salt Spray Test | Hrs | Top: 750 Hrs, Bottom: 300 Hrs |
| Humidity Test | Hrs | Top: 750 Hrs, Bottom: 300 Hrs |
| Scratch Hardness Test | Kg | Top: 1.5Kg pass, Bottom: 0.7Kg pass |
| Pencil Hardness | NA | H pass |
| Cross Hatch | NA | No Tape loss |
| Bend Test top/bottom | Thickness | 4T pass |
| Gloss Test @60 degree top/bottom | % | 35 +/- 5 |
| Solvent Rub test | DR | Top: 100 rubs, Bottom: 50 rubs pass |
| Liner marking | NA | LUXUME 0.35 MM TCT PPGL AZ70 GSM 550 MPa DD/MM/YYYY |
Ready to enhance the aesthetic appeal of your buildings?
For inquiries, orders, or to learn more about our products and services
Inside Luxume's Coated Steel Sheets
Understanding
the Layers of
Coated Steel
Sheets
This diagram illustrates the multiple layers involved in the production of coated steel sheets, highlighting their protective and functional coatings.
Downloads & Resources
Access essential documents to help you make informed decisions and ensure the best performance of Luxume roofing products.
